Clean Air Box Series (CAB)
Breathing Air Filtration System
Clean Air Box Series (CAB) Breathing Air Filtration System
Clean air. From a little yellow box.
Compliance
OSHA requires that employers provide their workers with Grade D breathing air. Bullard Clean Air Boxes provide 3-stage filtration and carbon monoxide (CO) monitoring to help meet this requirement.
Design
- Polycarbonate Pelican® Cases (Portable Units)
- Powder Coated Steel (Wall Mount Units)
3-Stage Filtration
Three stages of filtration remove oil, water, particulate, oil vapor and odors
1st Stage
Removes 95% of solid contaminants and bulk liquids from the breathing air, down to five microns, prolonging the life of the second and third stage elements.
2nd Stage
Removes extremely fine oil mists down to .01 microns. Maximum remaining filter efficiency is 99.9998%.
3rd Stage
Removes unpleasant oil and hydrocarbon vapors and odors from the air. Maximum remaining oil content is .003 ppm by weight. Filter efficiency is 99.9998%.
Filter change indicators visually alerts the operator to replace element Replacement filters compatible with other brands of filtration panels
CO Monitoring
Auto calibration takes approximately 90 seconds and requires no tools High intensity 90 dB alarm remote capable with strobe
Self-contained
- 70+ hours of operation on 8-AA batteries
- 110VAC power cord included
Visual display with Internal LCD and External LEDs
